Phonic Combo + is a composite tile with a refined white painted, monolithic, pre-finished face. It has an absorptive layer with an attenuating backer behind. Combo + not only has amazing acoustic properties (and meets Ministry of Education requirements) but also is a much better solution for seismic requirements. Performance data demonstrates an NRC of 0.85 and a minimum CAC of 42, that can be increased to a CAC of 52 quite easily.

The invention comprises two layers of material that are flexibly attached together with an air gap in between. This allows each of the layers to flex and vibrate and to define a cavity. The absorbent face is made from a compounded, high density glass-wool. The attenuating backer reduces sound transfer over office partitions and reduces rain noise from roofing. The resulting tile weight is only 7.5kg/m2. Patent is pending on this revolutionary design.

Phonic Combo + is a high performance ceiling tile which is user friendly and ideal for use in airports, offices, classrooms, boardrooms, museums and other commercial interiors.

This tile comes with a 30 year lifetime system warranty to withstand conditions up to 40° and 99% relative humidity without visible sag, when used with a T&R Interior Systems branded suspension system. Tiles should be installed in accordance with tiles should be installed in accordance with NZS1170.5 and the grid manufacturer’s instructions.

Absorption

• NRC 0.85
• SAA 0.94
• a_w 0.75

Attenuation

• CAC & D _n,c,w 42 with the ability to increase easily. (Acoustic tested in NZ)

LR > 87%

Fire Test: ISO 5660 Parts 1 & 2 - Group 1 – S

Moisture Rate: 1%

Est. R-Value R0.7

Sizes: 1200 x 600 mm, 600 x 600 mm (other sizes available on indent)

Weight: 7.5 kg/m2 (35 mm), 6.17 kg/m2 (45 mm)

Colours: White, black and ink-jet printed available by indent and MOQ

TESTING: If you would like any testing certificates, please contact us

WARRANTY: 30 year lifetime system warranty to withstand conditions up to 40° and 99% relative humidity without visible sag when used with a T&R brand suspension system.

Emissions, Sustainability and the Environment - For Green Star rated projects, Phonic Glasswool has been verified and meets the Greenguard Emission Certificate Standard.

For product warranties, completion documents and test reports, please contact T&R Interior Systems: info@tris.co.nz

In Service History

• Bayfield School, Auckland.
• Rangi Ruru School, Christchurch.
• RSA Rangiora
• Thornton School
• Lemonwood School
• Hornby High School
• Tauranga Airport
• Eastern Hutt School,
• Sacred Heart Girls College, New Plymouth
• Remarkables Primary School, Queenstown
• Massey School of Aviation, Palmerston North
• Taranaki Catherdral Music Room, New Plymouth
• Kapiti Performing Arts' College
• Te Pi Ipi Inga School, New Plymouth
• Wellington East Girl's School, Wellington
• Wellington Regional Economic Development Agency, Wellington

CASE STUDIES

 Lemonwood School  Weta Workshop Unleashed  Manukura  Tauranga Airport  Aotea College  Wellington East Girls' College  Rangi Ruru School  Rangiora RSA  Hornby Club  Starship Hospital PICU
